KMX-1 150cc

Product Size1850*760*1060 mm
Max. Speed61 – 80km/h
Min Ground Clearance250mm
Seat Height790mm
Wheel SizeFront 70/100-19 Rear 90/100-16
Max Power8.2KW/7000
Max Torque12N.m/5500

KAMAX 2022 off-road dirt bike designed for enduro beginner or kids, cradle frame structure, high strength and low vibration. The power system, suspension system and body structure are perfectly combined to provide excellent operability to the driver. Custom color available, off-road and on-road supported.

Share to

DM 20240424153927 008
DM 20240424153927 009
DM 20240424153927 010

LED Lights System

LED headlight, LED turn signals and LED taillight are equiped on this model.

DM 20240424153927 011

ZS-ZY150 Engine

Zongshen ZY150 Single Cylinder, 4-stroke, air cooled, Overhead cam, balance shaft.

DM 20240424153927 012

Disc Brake System

Front Brake: silver white pumps with polished handle, brake switch and white aviation oil pipe, double piston for lower pump.
Rear Brake: silver white pumps with brake switch, white aviation oil pipe and single piston for rear pump.

DM 20240424153927 013

Deep Lugs Yuanxing Rubber Tire

Front size: 70/100-19/P88, Rear size: 90/100-16/P89

DM 20240424153927 014

Low Seat Height for Kids or Beginners

Only 790mm seat height design for teenagers and cross country beginners to learn, train and play on the field.

DM 20240424153927 015

Digital Dashboard

The Intuitive and easy-to-read digital dashboard helps the driver to grasp the current status of the motorcycle.

DM 20240424153927 016
DM 20240424153927 017

Technical Description

Body size and weight
Wheel base1250(MM)
Rated carrying capacity150KG
Wheel specificationFront tires 70/100-19/, Rear tires 90/100-16
Sitting height790(MM)
Minimum ground clearance250(MM)
Fuel tank volume8(L)
Brake formFront and rear disc brakes
Power system
Engine styleZS 4-stroke ZY150
Type of the engineSingle cylinder/4-stroke/Air cooling/overhead cam/balance shaft type
Cylinder bore57.3×57.8
Maximum power8.2KW/7000
Maximum Torque12N.M/5500
Way of lubricationPressure, splash compound
Clutch typeManualwetmulti-piece
Gearshift Methodlnternational Five Gear
storage battery12V/3Ah lithium battery
lgnitionelectronic, CDI
Start methodKick & Electric start
Car frame /shock absorber/braking
Car framechrome-molybdenum steel with higher strength
Front shock absorberupside-down front shock absorber
Rear shock absorberBuilt-in airbag single rear shock absorber
Rear flat forkSilver rear flat fork
Front brakeThe front disc is equipped with dual-piston calipers and white aviation tube
Rear brakerear disc with single-piston calipers and white aviation tube
